Indian space agency on Tuesday will bring down its decommissioned satellite Megha-Tropiques-1 (MT1) in a controlled manner along with the French space agency CNES.

The satellite is to impact an uninhabited location in the Pacific Ocean, Indian Space Research Organisation (ISRO) said.

According to ISRO, it is gearing up for a challenging experiment of controlled re-entry of a decommissioned low Earth-orbiting satellite, namely Megha-Tropiques-1 (MT1), on March 7, 2023.

MT1 was launched on October 12, 2011, as a joint satellite venture of ISRO and the French space agency, CNES for tropical weather and climate studies.

Although the mission life of the satellite originally was to three years, the satellite continued to provide valuable data services for more than a decade supporting regional and global climate models till 2021.

The ISRO said the UN/IADC space debris mitigation guidelines recommend deorbiting an LEO (Low Earth Orbit) object at its end-of-life, preferably through controlled re-entry to a safe impact zone, or by bringing it to an orbit where the orbital lifetime is less than 25 years.

It is also recommended to carry out the “passivation” of onboard energy sources to minimize the risk of any post-mission accidental break-up.

The orbital lifetime of MT1, weighing about 1,000 kg, would have been more than 100 years in its 20-degree inclined operational orbit of 867 km altitude.

About 125 kg of onboard fuel remained unutilized at its end-of-mission which could pose risks for an accidental break-up.

This left-over fuel was estimated to be sufficient to achieve a fully controlled atmospheric re-entry to impact an uninhabited location in the Pacific Ocean, ISRO said.

Controlled re-entries involve deorbiting to very low altitudes to ensure impact occurs within a targeted safe zone.

Usually, large satellites/rocket bodies, which are likely to survive aero-thermal fragmentation upon re-entry, are made to undergo controlled re-entry to limit ground casualty risk.

However, all such satellites are specifically designed to undergo controlled re-entry at end-of-life, ISRO said.

MT1 was not designed for end-of-life (EOL) operations through controlled re-entry which made the entire exercise extremely challenging.

Furthermore, the onboard constraints of the aged satellite, where several systems had lost redundancy and showed degraded performance, and maintaining subsystems under harsher environmental conditions at much lower than originally designed orbital altitude added to the operational complexities.

“Innovative workarounds were implemented by the operations team based on the study, deliberations, and exchanges among the mission, operations, flight dynamics, aerodynamics, propulsion, controls, navigation, thermal, and other sub-system design teams across the ISRO centers, who worked in synergy to surmount these challenges,” the Indian space agency said.

An uninhabited area in the Pacific Ocean between 5 degrees S to 14 degrees S latitude and 119 degrees W to 100 degrees W longitude was identified as the targeted re-entry zone for MT1.

Since Aug 2022, 18 orbit maneuvers were performed to progressively lower the orbit.

In between the de-orbiting, aero-braking studies at different solar panel orientations were also carried out to gain better insights into the physical process of atmospheric drag affecting the orbital decay of the satellite.

The final de-boost strategy has been designed after taking into consideration several constraints, including visibility of the re-entry trace over ground stations, ground impact within the targeted zone, and allowable operating conditions of subsystems, especially the maximum deliverable thrust and the maximum firing duration of the thrusters.

The final two de-boost burns followed by the ground impact are expected to take place between 16.30 IST to 19.30 IST on March 7.

“Aero-thermal simulations show that no large fragments of the satellites are likely to survive the aerothermal heating during the re-entry,” ISRO said.

As a responsible space agency committed to safe and sustainable operations in outer space, ISRO proactively takes efforts for better compliance with the UN/IADC space debris mitigation guidelines on post-mission disposal of LEO objects.

The re-entry experiment of MT1 has been undertaken as a part of the ongoing efforts as this satellite with sufficient left-over fuel presented a unique opportunity to test the relevant methodologies and understand the associated operational nuances of post-mission disposal by direct re-entry into the Earth’s atmosphere.
